Owner's Manual
Table Of Contents
- Dell Server Management Pack Suite Version 5.0.1 For Microsoft System Center Operations Manager And System Center Essentials Installation Guide
- Overview
- Installing, Uninstalling, And Upgrading Dell Server Management Pack Suite
- Installing The Dell Server Management Pack Suite
- Upgrading Monitoring Features Using Dell Feature Management Dashboard
- Upgrading From Previous Management Packs
- Upgrading to OpsMgr 2012
- Post-Installation or Upgrade Tasks For The Dell Server Management Pack Suite
- Uninstalling The Dell Server Management Pack Suite
- Access Privileges
- Troubleshooting
- Importing The Dell Feature Monitoring Management Pack
- Override Task Parameters
- Feature Management Alerts
- Feature Management Host Server's Health Service Goes Down
- Creating Connections License Manager Domain Groups
- Feature Management Dashboard Is Not Getting Populated
- Feature Management Dashboard Is Taking Time To Populate
- Chassis And DRAC Overrides Not Getting Transferred After Upgrading To OpsMgr 2012
- Contacting Dell
Table 2. Supported Dell Devices
Devices Generation Features
Dell PowerEdge 9G, 10G, 11G
• Server In-band Monitoring
• Chassis Blade Correlation
12G
• Server In-band Monitoring
• Server Out-Of-Band Monitoring
• Chassis Blade Correlation
Dell PowerVault 9G, 10G, 11G
• Server In-band Monitoring
• Chassis Blade Correlation
Dell Remote Access Controller DRAC 5, iDRAC 6, iDRAC 7 DRAC Monitoring
Dell Chassis Management
Controller
CMC, DRAC/MC
• Chassis Monitoring
• Chassis Blade Correlation
Supported Firmware Versions
The following table lists the supported firmware versions for DRAC, iDRAC, and CMC devices.
Table 3. Supported Firmware Versions For DRAC And CMC Devices
DRAC CMC and DRAC/MC
iDRAC 7 Modular and Monolithic: version 1.0 CMC: versions 3.1 to 4.0
iDRAC 6 Modular: versions 1.5, 1.6, 3.2, and 3.3 DRAC/MC: versions 1.5 and later
iDRAC 6 Monolithic: versions 1.7 and 1.8
DRAC 5: versions 1.5 and 1.6
Management Server (MS) Requirements
Server In-Band Monitoring Requirements
Supported Operating Systems
For the list of supported operating systems for the management server for OpsMgr 2007, see technet.microsoft.com/en-
us/library/bb309428(en-us).aspx, and for OpsMgr 2012, see technet.microsoft.com/en-us/library/hh205990.aspx.
Software Requirements
The following table lists the software requirements in the Management Server for using the features of the suite.
Table 4. Pre-Requisites For Software
Software Purpose
DRAC Tools
OR
To discover Chassis Slot Summary and Server Modules
for CMC and DRAC/MC Chassis.
7
