Tasks Description
Upgrade DRAC Monitoring Feature If upgrading from previous versions of Dell Server
Management Pack Suite, the DRAC Monitoring feature
of the current version Dell Server Management Pack is
imported.
Remove DRAC Monitoring Feature Removes the DRAC Monitoring feature.
Chassis Monitoring
Import Chassis Monitoring Feature If the Monitoring feature is not installed, then the
Chassis Monitoring feature is imported.
Upgrade Chassis Monitoring Feature If upgrading from previous versions of Dell Server
Management Pack Suite, the Chassis Monitoring
feature of the current version Dell Server Management
Pack is imported.
Remove Chassis Monitoring Feature Removes the Chassis Monitoring feature.
Chassis Modular Server Correlation
Import Chassis Modular Server Correlation Feature If the Monitoring feature is not installed, then the
Chassis Modular Server Correlation feature is imported.
Upgrade Chassis Modular Server Correlation Feature If upgrading from previous versions of Dell Server
Management Pack Suite, the Chassis Modular Server
Correlation feature of Dell Server Management Pack is
imported.
Remove Chassis Modular Server Correlation Feature Removes the Chassis Blade Correlation Monitoring
feature.
Upgrading Monitoring Features Using Dell Feature Management
Dashboard
1. Launch the OpsMgr console.
2. From the navigation pane, click Monitoring.
3. Click Dell → Feature Management Dashboard.
On the Feature Management Dashboard pane, you can view the list of features installed, the version currently in
use, the version you can upgrade to, the level of monitoring, total licenses, and the licenses in use.
4. Select the feature you want to upgrade. For the list of available upgrade options for each feature, see Feature
Upgrade Matrix.
5. Under the Tasks pane, expand Dell Monitoring Feature Tasks.
NOTE: In System Center Operations Manager 2007 or System Center Essentials 2010 the Tasks pane is
referred to as Actions pane.
6. Click on the upgrade task you want to perform. For more information, see Feature Management Tasks.
7. On the Run Task upgrade screen, select Use the predefined Run As Account option.
8. Click Run.
