Untagged-network :
Networks : Network780
Configured-Interfaces : CAC00N2:ethernet1/1/22:2
----------------------------------------------------------
----------------------------------------------------------
Name : L3VLANUplink
Description : Uplink On L3VLAN Network800
ID : L3VLANUplink-800
Media Type : ETHERNET
Native Vlan : 0
Untagged-network :
Networks : Network800
Configured-Interfaces : CAC00N2:ethernet1/1/22:1
----------------------------------------------------------
----------------------------------------------------------
Name : L2VxLANUplink
Description : Uplink On L2VxLAN Network770
ID : L2VxLANUplink-770
Media Type : ETHERNET
Native Vlan : 0
Untagged-network :
Networks : Network770
Configured-Interfaces : CAC00N2:ethernet1/1/22:3
----------------------------------------------------------
----------------------------------------------------------
Name : L2VxLANUplink
Description : Uplink On L2VxLAN Network771
ID : L2VxLANUplink-771
Media Type : ETHERNET
Native Vlan : 0
Untagged-network : Network771
Networks :
Configured-Interfaces : CAC00N2:ethernet1/1/22:4
----------------------------------------------------------
----------------------------------------------------------
Name : L3Uplink
Description : Uplink On L3 Network600
ID : L3RUplink-600
Media Type : ETHERNET
Native Vlan : 0
Untagged-network : Network600
Networks :
Configured-Interfaces : AZY1234:ethernet1/1/21:2
----------------------------------------------------------
Supported
Releases
● MX9116n and MX5108n—10.5.0.1 or later
● SFS-supported OS10 switches—10.5.0.3 or later
show smartfabric upgrade-status
Displays all the information about the upgrade status.
Syntax
show smartfabric upgrade-status
NOTE: This command is accessible to users with sysadmin, secadmin, or netadmin roles.
Parameters None
Default Not applicable
Command Mode EXEC
Usage
Information
You can run this command on all the switches in the fabric. The output remains the same on all the switches.
Example
MX9116N-A1# show smartfabric upgrade-status
Opaque-id : ea89b7c4-de00-4fc9-ad54-9ed5bf61e300
