Dell DIAG OS

The following describes the Dell diagnostics. These instructions apply to systems for which the ONIE diagnostics are not

available.

Topics:

• Downloading the Diagnostic Package

• Viewing the Dell DIAGs Versions

• Viewing the CPLD Versions

• Installing or Upgrading DIAG Tools in the Dell DIAGs OS

• Restoring the Factory Defaults

Downloading the Diagnostic Package

To download the diagnostic package on your system, follow these steps.

You must load or update the DIAG-OS (diag installer image) using the onie-nos-install command in ONIE Install or ONIE-

Rescue mode. The DIAG-OS installer runs in two modes: Update mode or Install mode. In Update mode, the DIAG-OS updates

the existing DIAG-OS and boots back to ONIE. In Install mode, the DIAG-OS erases the existing DIAG-OS and loads the new

DIAG-OS.

NOTE: If you have a recovery USB plugged into your system, you must remove it prior to installing the DIAG-OS using the

onie-nos-install command.

NOTE: Before you begin, go to http://www.dell.com/support and download the diagnostic package. You will need your

Dell support access account to download the package.

1 Enter the onie-discovery-stop command to stop ONIE Discovery mode.

2 Assign an ip address to the management interface and verify the network connectivity.

ONIE:/ # ifconfig eth0 10.10.10.10/8

ONIE:/ # ifconfig eth0

eth0 Link encap:Ethernet HWaddr 4C:76:25:F4:F0:00

inet addr:10.10.10.10 Bcast:10.255.255.255 Mask:255.0.0.0

inet6 addr: fe80::4e76:25ff:fef4:f000/64 Scope:Link

UP BROADCAST RUNNING MULTICAST MTU:1500 Metric:1

RX packets:87 errors:0 dropped:0 overruns:0 frame:0

TX packets:51 errors:0 dropped:0 overruns:0 carrier:0

collisions:0 txqueuelen:1000

RX bytes:20042 (19.5 KiB) TX bytes:9548 (9.3 KiB)

Memory:dff40000-dff60000

ONIE:/ #

3 Upgrade the DIAG Installer. Again, boot to ONIE Rescue mode and install the onie diag installer.

Example of Removing the Existing DIAG OS and Installing a New Version

NOTE: In Install mode, the DIAG-OS installation removes any existing NOS and DIAG-OS partition. If you do not create

file /tmp/diag_os_install_mode, the DIAG-OS installs in Upgrade mode. In this case, the installation process

does NOT touch any existing NOS.

---------------------------------------------------------

Dell DIAG OS 22
