Parameter Specications
Storage Temperature –40° to 158°F (–40° to 70°C)
Storage Humidity 5 to 95%, non-condensing
Maximum Thermal Output 292.42 BTU/hr 85.7W
Maximum operational altitude 10,000 feet (3,048 meters)
Maximum non-operational altitude No performance degradation to 35,000 feet (10,668 meters)
Shock SV0115 — ODM
Table 6. AC power requirements
Parameter Specications
Power Supply 100–240 VAC 50/60 Hz
Maximum Current Draw Per System
3A @ 100vac
2A @ 200vac
PSU Maximum Power Capability
PSU Maximum Power Capability, North America Only
224.4 Watts
424.0 Watts
Typical Power Consumption 200 Watts
Reliability MTBF 1,154,397 hours
IEEE Standards
The S3048–ON complies with the following IEEE standards.
• 802.3ab Gigabit Ethernet (1000BASE-T)
• 802.3ae 10 Gigabit Ethernet (10GBASE-X)
• 802.3u Fast Ethernet (100BASE-TX)
• 802.3z Gigabit Ethernet (1000BASE-X)
Agency compliance
The S3048–ON is designed to comply with the following safety and agency requirements:
USA Federal Communications Commission Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules.
These limits are designated to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy. If it is not installed and used in accordance to the
instructions, it may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference, in which case users will be required to take whatever measures necessary to correct the interference at their own
expense.
Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Dell Networking is not
responsible for any radio or television interference caused by using other than recommended cables and connectors or by unauthorized
changes or modications in the equipment. Unauthorized changes or modication could void the user’s authority to operate the equipment.
