As an option of the show processes cpu command, this option displays CPU usage
for the designated stack member. Or, as an option of memory, this option limits the
output of memory statistics to the designated stack member. Refer to Example (stack-
unit).
summary (OPTIONAL) Enter the keyword summary to view a summary view CPU utilization of
processes related to line card processing. Refer to Example (summary).
ipc (OPTIONAL) Enter the keyword ipc to display interprocess communication statistics.
memory (OPTIONAL) Enter the keyword memory to display memory statistics. Refer to Example
(memory).
Command Modes
• EXEC
• EXEC Privilege
Supported Modes All Modes
Command History
Version Description
8.3.17.0 Supported on the M I/O Aggregator.
Example (summary)
Dell#show processes cpu summary
CPU utilization 5Sec 1Min 5Min
-------------------------------------------
UNIT1 4% 3% 2%
Example
(management-unit)
Dell#show processes cpu management-unit 5
CPU utilization for five seconds: 4%/0%; one minute: 4%; five minutes: 4%
PID Runtime(ms) Invoked uSecs 5Sec 1Min 5Min TTY
Process
0x00000000 2120 212 10000 3.77% 3.77% 3.77% 0
system
0x00000112 2472940 247294 10000 0.79% 0.61% 0.65% 0
sysdlp
0x000000e4 495560 49556 10000 0.20% 0.25% 0.24% 0
sysd
0x0000013d 34310 3431 10000 0.00% 0.02% 0.00% 0
lacp
0x00000121 4190 419 10000 0.00% 0.02% 0.00% 0
iscsiOpt
PID Runtime(ms) Invoked uSecs 5Sec 1Min 5Min TTY Process
Dell#
Example (stack-unit)
Dell#show process cpu stack-unit 1
CPU utilization for five seconds: 4%/0%; one minute: 3%; five minutes: 2%
PID Runtime(ms) Invoked uSecs 5Sec 1Min 5Min TTY Process
0x763a3000 17981680 1798168 10000 3.00% 2.67% 2.67% 0 KP
0x762ba000 0 0 0 0.00% 0.00% 0.00% 0 debugagt
0x762d9000 0 0 0 0.00% 0.00% 0.00% 0 F10StkMgr
0x762f8000 214590 21459 10000 0.00% 0.00% 0.00% 0 lcMgr
0x76319000 7890 789 10000 0.00% 0.00% 0.00% 0 dla
0x76344000 155770 15577 10000 0.00% 0.00% 0.02% 0 sysAdmTsk
0x76363000 583230 58323 10000 0.00% 0.00% 0.02% 0 timerMgr
0x76381000 658850 65885 10000 0.00% 0.17% 0.08% 0 PM
0x76299000 80110 8011 10000 0.00% 0.00% 0.00% 0 diagagt
66 Control and Monitoring
