Example
Dell#show configuration lock
Configure exclusively locked by the following line:
Line : vty 0
Line number : 2
User : admin
Type : AUTO
State : LOCKED
Ip address : 10.11.9.97
Dell#
show cpu-trac-stats
Display the CPU trac statistics.
Syntax
show cpu-traffic-stats [port number | all]
Parameters
port number (OPTIONAL) Enter the port number to display trac statistics on that port only. The
range is from 1 to 1568.
all (OPTIONAL) Enter the keyword all to display trac statistics on all the interfaces
receiving trac, sorted based on the trac.
Defaults all
Command Modes EXEC
Supported Modes All Modes
Command History
Version Description
9.9(0.0) Introduced on the FN IOM.
9.4(0.0) Supported on the FN I/O Aggregator.
8.3.17.0 Supported on the M I/O Aggregator.
Usage Information Trac statistics are sorted on a per-interface basis; the interface receiving the most trac is displayed rst. All
CPU and port information is displayed unless a specic port or CPU is specied. Trac information is displayed for
router ports only; not for management interfaces. The trac statistics are collected only after the debug cpu-
traffic-stats command is executed; not from the system bootup.
NOTE: After debugging is complete, use the no debug cpu-traffic-stats command to shut o
trac statistics collection.
Example
Dell#show cpu-traffic-stats
Processor : CP
--------------
Received 100% traffic on TenGigabitEthernet 8/2 Total packets:100
LLC:0, SNAP:0, IP:100, ARP:0, other:0
Unicast:100, Multicast:0, Broadcast:0
Dell#
Related Commands debug cpu-trac-stats — enables CPU trac statistics for debugging.
Control and Monitoring 61
