Stackunit level0 diag issued at Tue May 15, 2012 11:11:47 AM.
Current diag status: Unit diags are terminated.
Total number of diags: 17
Number of diags performed: 1
Number of diags passed: 1
Number of diags failed: 0
Number of diags pending: 16
Last Test executed: POWERRAILSTATUSTEST
Last notification received at: Tue May 15, 2012 11:12:24 AM
----------------------------------------------------------------
Example 3 (show
diag testcase stack-
unit Command)
Dell#show diag testcase stack-unit 0
**************************** Navasota Diagnostics Test
*************************
Test ID Test Description Test Level
------- ---------------- ----------
1 POWERRAILSTATUSTEST Level0
2 OPTMODSLOTPOWERSTATUSTEST Level0
3 TSENSORACCESSTEST Level0
4 RTCPRESENCETEST Level0
5 CPUSDRAMPRESENCETEST Level0
6 CPUSDRAMSIZETEST Level0
7 USBAACCESSTEST Level0
8 USBHOSTCONTROLLERACCESSTEST Level0
9 SDFLASHACCESSTEST Level0
10 QSFPPLUSPOWERMODETEST Level0
11 CPLDPRESENCETEST Level0
12 FLASHACCESSTEST Level0
13 BOARDREVTEST Level0
14 MGMTPHYPRESENCETEST Level0
15 OPTMODTYPETEST Level0
16 QSFPPLUSPRESENCETEST Level0
17 CPUTYPEDETECTTEST Level0
101 RTCFUNCTIONTEST Level1
102 RTCROLLOVERTEST Level1
103 GPIOACCESSTEST Level1
104 PSOCACCESSTEST Level1
105 PCIEBCM56846ACCESSTEST Level1
106 CPUSDRAMACCESSTEST Level1
107 CPUSDRAMDATALINETEST Level1
108 CPUSDRAMADDRESSLINETEST Level1
109 USBFILECOPYTEST Level1
110 FLASHRWTEST Level1
111 I2CSTRESSTEST Level1
112 AVSPOWERCNTRLACCESSTEST Level1
113 SERVERPORTPHYACCESSTEST Level1
114 SERVERPORTPHYRWTEST Level1
115 QSFPPLUSPHYACCESSTEST Level1
116 QSFPPLUSPHYRWTEST Level1
117 QSFPPLUSPHYEXTLINKTEST Level1
118 QSFPPLUSEEPROMTEST Level1
119 OPTMODPHYACCESSTEST Level1
120 OPTMODPHYRWTEST Level1
121 OPTMODPHYEXTLINKTEST Level1
122 OPTMODMODULEEEPROMTEST Level1
123 MGMTPHYACCESSTEST Level1
124 SDFLASHFILECOPYSTRESSTEST Level1
201 QSFPPLUSPHYLNKSPEEDTEST Level2
202 OPTMODPHYLNKSPEEDTEST Level2
203 MGMTPHYLOOPBACKTEST Level2
204 MGMTMACLOOPBACKTEST Level2
205 CPUSNAKESERVERPORTPHYLPBKTEST Level2
206 CPUSNAKESERVERPORTMACLPBKTEST Level2
207 CPUSNAKEQSFPPPHYLPBKTEST Level2
208 CPUSNAKEQSFPPMACLPBKTEST Level2
209 CPUSNAKEOPTMODPHYLPBKTEST Level2
210 CPUSNAKEOPTMODMACLPBKTEST Level2
Total Diagnostic Testcases in All Levels: 51
