Virtual Link Trunking (VLT)
VLT allows physical links between two chassis to appear as a single virtual link to the network core. VLT eliminates the requirement for
Spanning Tree protocols by allowing link aggregation group (LAG) terminations on two separate distribution or core switches, and by
supporting a loop-free topology. VLT provides Layer 2 multipathing, creating redundancy through increased bandwidth and enabling multiple
parallel paths between nodes and load-balancing trac where alternative paths exist.
NOTE: When you launch the VLT link, the VLT peer-ship is not established if any of the following is TRUE:
• The VLT System-MAC congured on both the VLT peers do not match.
• The VLT Unit-Id congured on both the VLT peers are identical.
• The VLT System-MAC or Unit-Id is congured only on one of the VLT peers.
• The VLT domain ID is not the same on both peers.
If the VLT peer-ship is already established, changing the System-MAC or Unit-Id does not cause VLT peer-ship to go down.
Also, if the VLT peer-ship is already established and the VLT Unit-Id or System-MAC are congured on both peers, then changing the
CLI congurations on the VLT Unit-Id or System-MAC is rejected if any of the following become TRUE:
• After making the CLI conguration change, the VLT Unit-Id becomes identical on both peers.
• After making the CLI conguration change, the VLT System-MAC do not match on both peers.
When the VLT peer-ship is already established, you can remove the VLT Unit-Id or System-MAC conguration from either or both
peers. However, removing conguration settings can cause the VLT ports to go down if you congure the Unit-Id or System-MAC on
only one of the VLT peers.
Topics:
• back-up destination
• clear vlt statistics
• lacp ungroup member-independent
• peer-link port-channel
• show vlt backup-link
• show vlt brief
• show vlt detail
• show vlt mismatch
• show vlt role
• show vlt statistics
• stack-unit iom-mode
• system-mac
• unit-id
• vlt domain
• vlt-peer-lag port-channel
