Users Guide

access-list-name
ipv6 access-list-
name
(Optional) Enter both an IPv4 and IPv6 access list name.
Defaults As above.
Command Modes CONFIGURATION
Supported Modes Programmable-Mux (PMUX)
Command History
This guide is platform-specic. For command information about other platforms, refer to the relevant Dell
Networking OS Command Line Reference Guide.
The following is a list of the Dell Networking OS version history for this command.
Version Description
9.9(0.0)
Introduced on the M I/O Aggregator.
Usage Information The following Example species the group named harig as a version 3 user requiring both authentication and
encryption and read access limited to the read named rview.
NOTE: The number of congurable groups is limited to 16 groups.
Example
Dell#conf
Dell(conf)# snmp-server group harig 3 priv read rview
Dell#
Related Commands
show snmp group— displays the group name, security model, view status, and storage type of each group.
snmp-server host
Congure the recipient of an SNMP trap operation.
Syntax
snmp-server host ip-address | ipv6-address [vrf vrf-name] traps | informs
[version 1 | 2c | 3] [auth | no auth | priv] [community-string] [udp-port port-
number] [notification-type]
To remove the SNMP host, use the no snmp-server host ip-address [vrf vrf-name] traps |
informs [version 1 | 2c | 3] [auth | noauth | priv] [community-string] [udp-
port number] [notification-type] command.
Parameters
ip-address Enter the keyword host then the IP address of the host (congurable hosts is limited to
16).
ipv6-address Enter the keyword host then the IPv6 address of the host in the x:x:x:x::x format.
NOTE: The :: notation species successive hexadecimal elds of zero.
vrf vrf-name Enter the keyword vrf and then the name of the VRF that the SNMP server uses to
connect to the host.
362 Simple Network Management Protocol (SNMP) and Syslog
