Field Description
Line Protocol Indicates whether the interface is administratively up
or down
Utilization (In Percent) Trac usage in percentage of the packets processed
by the particular member interface
Example
Dell#show link-bundle-distribution port-channel
Link-bundle trigger threshold - 60
LAG bundle - 1 Utilization[In Percent] - 0 Alarm State - Inactive
Interface Line Protocol Utilization[In Percent]
Te 0/5 Up 0
Te 0/13 Up 0
show port-channel-ow
Display an egress port in a given port-channel ow.
Syntax
show port-channel-flow port-channel number incoming-interface interface { src-
mac address dest-mac address {vlan vlanid | ether-type }} [ src-ip address
dest-ip address ] [ src-port number dest-port number ]
Parameters
port-channel
number
Enter the keywords port-channel then the number of the port channel to display ow
information. The range is from 1 to 128.
incoming-interface
interface
Enter the keywords incoming-interface then the interface type and slot/port or
number information:
• For a 10-Gigabit Ethernet interface, enter the keyword TenGigabitEthernet then
the slot/port information.
src-mac address Enter the keywords src-mac then the MAC source address in the nn:nn:nn:nn:nn:nn
format.
dest-macaddress Enter the keywords dest-mac then the MAC destination address in the
nn:nn:nn:nn:nn:nn format.
vlan
vlan-id
Enter the keyword vlan then the VLAN ID. The range is from 1 to 4094.
ether-type Enter the keywords ether-type then the ether-value in the XX:XX format.
src-ip address Enter the keywords src-ip then the IP source address in IP address format.
dest-ip address Enter the keywords dest-ip then the IP destination address in IP address format.
src-port number Enter the keywords src-port then the source port number. The range is from 1 to
65536. The default is None.
dest-port number Enter the keywords dest-port then the destination port number. The range is from 1 to
65536. The default is None.
Command Modes EXEC
Supported Modes All Modes
Link Aggregation Control Protocol (LACP) 271
