Oper: State BCEGIKNP Key 1 Priority 128
Dell#
Example (Sys-id)
Dell#show lacp 1 sys-id
Actor System ID: Priority 32768, Address 0001.e800.a12b
Partner System ID: Priority 32768, Address 0001.e801.45a5
Dell#
Example (Counter)
Dell#show lacp 1 counters
----------------------------------------------------
LACP PDU Marker PDU Unknown Illegal
Port Xmit Recv Xmit Recv Pkts Rx Pkts Rx
-----------------------------------------------------
TenGig 0/1 200 200 0 0 0 0
Dell#
Related Commands
clear lacp counters — Clears the LACP counters.
show interfaces port-channel — Displays the information on congured Port Channel groups.
show link-bundle-distribution port-channel
Display the trac-handling and utilization of the member interfaces of the port channel.
Syntax
show link-bundle-distribution port-channel
Command Modes
EXEC
EXEC Privilege
Supported Modes All Modes
Command History
Version Description
9.3.0.0 Introduced on the M I/O Aggregator
Usage Information The following table describes the output elds of this show command:
Table 2. Output Fields
Field Description
Link-bundle trigger threshold Threshold value that is the checkpoint, exceeding
which the link bundle is marked as being overutilized
and alarm is generated
LAG bundle number Number of the LAG bundle
Utilization (In Percent) Trac usage in percentage of the packets processed
by the port channel
Alarm State Indicates whether an alarm is generated if
overutilization of the port channel occurred. Possible
values are Active and Inactive
Interface Slot and port number, and the type of the member
interface of the port channel
270 Link Aggregation Control Protocol (LACP)
