• EXEC Privilege
Supported Modes All Modes
Command History
Version Description
9.9(0.0) Introduced on the FN IOM and added support to display the interface congurations
corresponding to a range of ports.
9.4(0.0) Supported on the FN I/O Aggregator.
8.3.17.0 Supported on the M I/O Aggregator.
Example
Dell#show interface status
Port Description Status Speed Duplex Vlan
Te 0/1 Down Auto Auto --
Te 0/2 Down Auto Auto --
Te 0/3 Down Auto Auto --
Te 0/4 Down Auto Auto --
Te 0/5 Down Auto Auto --
Te 0/6 Down Auto Auto --
Te 0/7 Down Auto Auto --
Te 0/8 Up 1 0000 Mbit Full --
Te 0/9 Down Auto Auto --
Te 0/10 Down Auto Auto --
Te 0/11 Down Auto Auto --
Te 0/12 Down Auto Auto --
Te 0/13 Down Auto Auto --
Te 0/14 Down Auto Auto --
Te 0/15 Down Auto Auto --
Te 0/16 Up 10000 Mbit Full --
show interfaces switchport
Display only virtual and physical interfaces in Layer 2 mode. This command displays the Layer 2 mode interfaces’ IEEE 802.1Q tag status
and VLAN membership.
Syntax
show interfaces switchport [interface | stack-unit unit-id ]
Parameters
interface (OPTIONAL) Enter one of the following keywords and slot/port or number information:
• For a 10-Gigabit Ethernet interface, enter the keyword TenGigabitEthernet
followed by the slot/port information.
• Enter the keyword backup to view the backup interface for this interface.
NOTE: This command also enables you to view information corresponding to a
range of ports.
• For physical interfaces, you can specify multiple ports as slot/port-range.
For example, if you want to display information corresponding to all ports
between 1 and 4, specify the port range as show interfaces
interface-type 1/1 - 4.
• For port–channel interfaces, you can specify multiple ports as port-range.
For example, if you want to display information corresponding to all ports
between 1 and 4, specify the port range as show interfaces port—
channel 1 - 4.
Interfaces 225
