TenGigabitEthernet 0/7 NO up down
TenGigabitEthernet 0/8 YES up up
show interfaces port-channel
Display information on congured Port Channel groups.
Syntax
show interfaces port-channel [channel-number] [brief| description]
Parameters
channel-number For a Port Channel interface, enter the keyword port-channel followed by a number.
The range is from 1 to 128.
brief (OPTIONAL) Enter the keyword brief to display only the port channel number, the
state of the port channel, and the number of interfaces in the port channel.
description (OPTIONAL) Enter the keyword description to display interface information with
description.
NOTE: This command also enables you to view information corresponding to a range of ports.
• For port-channel interfaces, you can specify multiple ports as port-range. For example, if you want to
display information corresponding to all ports between 1 and 4, specify the port range as show
interfaces port-channel 1 - 4
.
Command Modes
• EXEC
• EXEC Privilege
Supported Modes All Modes
Command History
Version Description
9.9(0.0) Introduced on the FN IOM and added support to display the interface congurations
corresponding to a range of ports.
9.7(0.0) Introduced on the M I/O Aggregator.
9.4(0.0) Supported on the FN I/O Aggregator.
Usage Information The following describes the show interfaces port-channel command shown in the following example.
Field Description
Port-Channel 1... Displays the status of LAG. In the Example, the status of the LAG, LAG fate-sharing
group (“Failover-group”) is listed.
Hardware is... Displays the interface’s hardware information and its assigned MAC address.
Port-channel is
part...
Indicates whether the LAG is part of a LAG fate-sharing group (“Failover-group”).
Internet address... States whether an IP address is assigned to the interface. If an IP address is assigned,
that address is displayed.
MTU 1554... Displays link and IP MTU.
LineSpeed Displays the interface’s line speed. For a port channel interface, it is the line speed of the
interfaces in the port channel.
Members in this... Displays the interfaces belonging to this port channel.
Interfaces 221
