NOTE: This command also enables you to view information corresponding to a
range of ports.
• You can specify multiple ports as slot/port-range. For example, if you
want to display information corresponding to all ports between 1 and 4, specify
the port range as show interfaces interface-type 1/1 - 4.
Command Modes
• EXEC
• EXEC Privilege
Supported Modes All Modes
Command History
Version Description
9.9(0.0) Added support to display the interface congurations corresponding to a range of ports.
9.6(0.0) Added support for Auto-LAG on the M I/O Aggregator.
8.3.17.0 Supported on the M I/O Aggregator
Usage Information
Use this show interfaces command for details on a specic interface. Use the show interfaces
stack-unit command for details on all interfaces on the designated stack unit.
On the M I/O Aggregator, the show interface output displays incorrect rate information details over time for link
monitoring when the rate-interval is congured for 5 seconds. Dell Networking recommends using higher rate-
intervals such as 15 to 299 seconds to minimize the errors seen.
NOTE: In the CLI output, the power value will be rounded to a 3-digit value. For receive/transmit power
that is less than 0.000, an snmp query will return the corresponding dbm value even though the CLI
displays as 0.000.
NOTE: After the counters are cleared, the line-rate continues to increase until it reaches the maximum
line rate. When the maximum line rate is reached, there will be no change in the line-rate.
User Information
The following describes the show interfaces command shown in the 10G example below.
Line Description
TenGigabitEthernet
2/0...
Displays the interface’s type, slot/port, and administrative and line protocol status.
Hardware is... Displays the interface’s hardware information and its assigned MAC address.
Interface index... Displays the interface index number used by SNMP to identify the interface.
Internet address... States whether an IP address is assigned to the interface. If an IP address is assigned,
that address is displayed.
MTU 1554... Displays link and IP MTU information. If the chassis is in Jumbo mode, this number can
range from 576 to 12000.
LineSpeed Displays the interface’s line speed.
ARP type:... Displays the ARP type and the ARP timeout value for the interface.
Last clearing... Displays the time when the show interfaces counters where cleared.
Queuing strategy... States the packet queuing strategy. FIFO means rst in rst out.
Input Statistics: Displays all the input statistics including:
