Supported Modes All Modes
Command History
Version Description
8.3.17.0 Supported on the M I/O Aggregator.
Usage Information When creating an interface range, interfaces appear in the order they are entered; they are not sorted. The
command veries that interfaces are present (physical) or congured (logical). Important things to remember:
• Bulk conguration is created if at least one interface is valid.
• Non-existing interfaces are excluded from the bulk conguration with a warning message.
• The interface range prompt includes interface types with slot/port information for valid interfaces. The prompt
allows for a maximum of 32 characters. If the bulk conguration exceeds 32 characters, it is represented by an
ellipsis ( ... ).
• When the interface range prompt has multiple port ranges, the smaller port range is excluded from the prompt.
• If overlapping port ranges are specied, the port range is extended to the smallest start port and the biggest
end port.
Example-Bulk
Conguration
Warning Message
Dell(conf)#interface range tengig 2/0 - 1 , tengig 10/0 , tengig 3/0
, fa 0/0
% Warning: Non-existing ports (not configured) are ignored by
interface-range
Example-Interface
Range prompt with
Multiple Ports
Dell(conf)#interface range tengig 2/0 - 23 , tengig 2/1 - 10
Dell(conf-if-range-tengig-2/0-23#
Example-Interface
Range prompt
Overlapping Port
Ranges
Dell(conf)#interface range tengig 2/1 - 11 , tengig 2/1 - 23
Dell(conf-if-range-tengig-2/1-23#
Only VLAN and port-channel interfaces created using the interface vlan and vlan tagged commands can
be used in the interface range command.
Use the show running-config command to display the VLAN and port-channel interfaces. VLAN or port-
channel interfaces that are not displayed in the
show running-config command cannot be used with the
bulk conguration feature of the interface range command. You cannot create virtual interfaces (VLAN,
Port-channel) using the interface range command.
NOTE: If a range has VLAN, physical, and port-channel interfaces, only commands related to physical
interfaces can be bulk congured. To congure commands specic to VLAN or port-channel, only those
respective interfaces should be congured in a particular range.
Example-Single
Range Bulk
Conguration
Dell(conf)# interface range tengigabitethernet 5/1 - 23
Dell(conf-if-range)# no shutdown
Dell(conf-if-range)#
Example-Multiple
Range Bulk
Conguration
Gigabit Ethernet and
Ten Gigabit Ethernet
The following example shows how to use commas to add dierent interface types to the range enabling all
TenGigabit Ethernet interfaces in the range 5/1 to 5/23 and both Ten Gigabit Ethernet interfaces 1/1 and 1/2.
Dell(conf-if)# interface range tengigabitethernet 5/1 - 23, tengigabitethernet
1/1 - 2
Dell(conf-if-range)# no shutdown
Dell(conf-if-range)#
