Field Description
Fabric-Name Name of a SAN fabric.
Fabric ID The ID number of the SAN fabric to which FC trac is forwarded.
VLAN ID The dedicated FCoE VLAN used to transport FCoE storage trac between servers and a
fabric over the NPIV proxy gateway. The congured VLAN ID must be the same as the
fabric ID.
VLAN priority FCoE trac uses VLAN priority 3. (This setting is not user-congurable.)
FC-MAP FCoE MAC address-prex value - The unique 24-bit MAC address prex that identies a
fabric.
FKA-ADV-period Time interval (in seconds) used to transmit FIP keepalive advertisements.
FCF Priority The priority used by a server to select an upstream FCoE forwarder.
Cong-State Indicates whether the congured FCoE and FC parameters in the FCoE map are valid:
Active (all mandatory FCoE and FC parameters are correctly congured) or Incomplete
(either the FC-MAP value, fabric ID, or VLAN ID are not correctly congured).
Oper-State Operational status of link to the fabric: Up (link is up and transmitting FC trac), Down
(link is down and not transmitting FC trac), Link-wait (link is up and waiting for FLOGI to
complete on peer FC port), or Removed (port has been shut down).
Members M I/O Aggregator with the FC Flex IO module Ethernet and FC ports that are members
of the dedicated FCoE VLAN that carries storage trac to the specied fabric.
Example
Dell#show fcoe-map brief
Fabric-Name Fabric-Id Vlan-Id FC-MAP FCF-Priority Config-State Oper-State
test 16 16 0efc02 128 ACTIVE UP
cnatest 1003 1003 0efc03 128 ACTIVE UP
sitest 1004 1004 0efc04 128 ACTIVE DOWN
Dell#show fcoe-map si
Fabric Name si
Fabric Id 1004
Vlan Id 1004
Vlan priority 3
FC-MAP 0efc04
FKA-ADV-Period 8
Fcf Priority 128
Config-State ACTIVE
Oper-State DOWN
Members
Related Commands
fcoe-map — creates an FCoE map which contains the parameters used in the communication between servers
and a SAN fabric.
