Total DCBX Frames received 6
Total DCBX Frame errors 0
Total DCBX Frames unrecognized 0
show interface ets
Displays the ETS conguration applied to egress trac on an interface, including priority groups with priorities and bandwidth allocation.
Syntax
show interface port-type slot/port ets {summary | detail}
Parameters
port-type slot/port
ets
Enter the port-type slot and port ETS information.
{summary | detail} Enter the keyword summary for a summary list of results or enter the keyword detail
for a full list of results.
NOTE: This command also enables you to view information corresponding to a range of ports.
• You can specify multiple ports as slot/port-range. For example, if you want to display information
corresponding to all ports between 1 and 4, specify the port range as show interfaces
interface-type 1/1 - 4.
Command Modes CONFIGURATION
Supported Modes All Modes
Command History
Version Description
9.9(0.0) Introduced on the FN IOM and added support to display the interface congurations
corresponding to a range of ports.
9.4(0.0) Supported on the FN I/O Aggregator.
9.2(0.0) Introduced on the M I/O Aggregator.
8.3.16.1 Introduced on the MXL 10/40GbE Switch IO Module.
Usage Information
To clear ETS TLV counters, use the clear ets counters interface port-type slot/port
command.
The following describes the show interface summary command shown in the following example.
Field Description
Interface Interface type with stack-unit and port number.
Max Supported TC
Group
Maximum number of priority groups supported.
Number of Trac
Classes
Number of 802.1p priorities currently congured.
Admin mode ETS mode: on or o. When on, the scheduling and bandwidth allocation congured in an
ETS output policy or received in a DCBX TLV from a peer can take eect on an interface.
Admin Parameters ETS conguration on local port, including priority groups, assigned dot1p priorities, and
bandwidth allocation.
Remote Parameters ETS conguration on remote peer port, including admin mode (enabled if a valid TLV was
received or disabled), priority groups, assigned dot1p priorities, and bandwidth allocation.
