Setup Guide

show ip
accounting
access-
lists Field
Description
“seq 5...” Displays the filter. If the keywords count or byte were configured in the filter,
the number of packets or bytes the filter processes is displayed at the end of the
line.
“order 4” Displays the QoS order of priority for the ACL entry.
Example
DellEMC# show ip accounting access-list
!
Standard Ingress IP access list test on TenGigabitEthernet 0/88
Total cam count 2
seq 5 permit 1.1.1.0/24 any negotiate 150 monitor 300 count (0 packets)
seq 10 deny 2.1.1.0/24 count (0 packets)
DellEMC#
DellEMC# show ip accounting access-list L3-ACL vrf vrf3
!
Standard Ingress IP access list L3-ACL on vrf3
Total cam count 3
seq 5 permit 10.1.2.0/24 any negotiate 150 monitor 300 count (0 packets)
seq 10 permit 20.1.2.0/24
seq 15 permit 30.1.2.0/24
DellEMC#
Standard IP ACL Commands
When you create an ACL without any rule and then apply it to an interface, the ACL behavior reflects an implicit permit.
The platform supports both Ingress and Egress IP ACLs.
NOTE: Also refer to the Commands Common to all ACL Types and Common IP ACL Commands sections.
deny
To drop packets with a certain IP address, configure a filter.
Syntax
deny {source | any | host {ip-address}} [count [bytes] | log] [dscp value]
[ecn value] [fragments] [monitor] [no-drop] [order]
To remove this filter, you have two choices:
● Use the no seq sequence-number command if you know the filter’s sequence number.
● Use the no deny {source [mask] | any | host ip-address} command.
Parameters
source Enter the IP address in dotted decimal format of the network from which the
packet was sent.
any Enter the keyword any to specify that all routes are subject to the filter.
host ip-address Enter the keyword host and then enter the IP address to specify a host IP address
only.
count (OPTIONAL) Enter the keyword count to count the packets.
bytes (OPTIONAL) Enter the keyword bytes to count the bytes.
log (OPTIONAL) Enter the keyword log to enter ACL matches in the log.
Access Control Lists (ACL) 189
