Reference Guide
Table Of Contents
- Dell Systems Management - OpenManage Software Support Matrix Version 7.3
- Introduction
- What Is New In This Release
- Structure Of This Guide
- Accessing Documents From Dell Support Site
- Supported Dell OpenManage Systems Management Software
- Where Can I find The Server Administrator One-to-One Agent
- Supported Dell OpenManage Change Management Software
- Supported Dell OpenManage Systems Management Consoles
- Supported Dell Remote Access Controllers And Solutions
- Supported Browsers
- Network Interface Controllers And Supported Operating Systems
- RAID Controller Supported Servers, Operating Systems, Firmware, And Driver Versions
- Supported GUI Languages
- Supported Dell OpenManage Systems Management Software
- Supported Dell OpenManage Change Management Software
- Supported Dell OpenManage Systems Management Consoles
- Dell OpenManage Essentials v1.1
- Dell OpenManage Power Center v1.2
- Supported Microsoft Windows Operating Systems for Power Center v1.2
- Supported Linux Operating Systems For Power Center v1.2
- Supported Virtualization Operating Systems For Power Center 1.2
- Dell OpenManage Server Administrator v7.3
- Supported Microsoft Windows Operating Systems for Server Administrator and Server Administrator Web Server
- Supported Linux Operating Systems For Server Administrator And Server Administrator Web Server
- Supported Virtualization Operating Systems For Server Administrator And Server Administrator Web Server
- Supported Operating Systems For Server Administrator Web Server On Your Managed System (Servers)
- Dell OpenManage IT Assistant
- Supported Microsoft Windows Operating Systems for IT Assistant
- Supported Linux Operating Systems For IT Assistant
- Supported Virtualization Operating Systems For IT Assistant
- Dell OpenManage Systems Management Tools And Utilities
- Supported Microsoft Windows Pre-installation Environment For Deployment Toolkit v4.2
- DRAC tools that include RACADM, VMCLI, and iVMCLI
- Supported Microsoft Windows Operating Systems For The RACADM Utility
- Supported Linux Operating Systems For The RACADM Utility
- Supported Virtualization Operating Systems For The RACADM Utility
- Supported Microsoft Windows Operating Systems For VMCLI And iVMCLI
- Supported Linux Operating Systems For The VMCLI And iVMCLI
- IPMITool In-Band
- Supported Microsoft Windows Operating Systems For IPMITool In-Band
- Supported Linux Operating Systems for IPMITool In-Band
- IPMITool Out-of-Band
- Supported Microsoft Windows Operating Systems For IPMITool Out-of-Band
- Supported Linux Operating Systems for IPMITool Out-of-Band
- Supported Microsoft Windows Operating Systems For IPMITool
- Supported Linux Operating Systems For IPMITool
- Supported Virtualization Operating Systems for IPMITool
- Supported Dell Remote Access Controllers And Solutions
- Lifecycle Controller — Supported Dell Systems and Operating Systems
- Supported Browsers
- Network Interface Controllers And Supported Operating Systems
- RAID Controller Supported Servers, Operating Systems, Firmware, And Driver Versions
- Linux Driver Included In RPM*
- PERC 5/E Adapter
- PERC 5/i Adapter and Integrated
- SAS 5/iR Adapter and Integrated
- SAS 5/i Integrated
- SAS 5/E Adapter
- PERC 6/i Adapter, Integrated, and Modular
- CERC 6/i Integrated
- PERC 6/E Adapter
- SAS 6/iR Integrated and Adapter
- SAS 6/int Modular
- SAS 6 Gbps HBA
- LSI Logic 1020/1030 Ultra320 SCSI Adapter
- PERC H700 Adapter, Integrated, and Modular
- PERC H800 Adapter
- PERC H200 Adapter, Integrated, and Modular
- PERC H310 Adapter, Mini Blade, And Mini Monolithic
- PERC H710 Adapter, Mini Blade, and Mini Monolithic
- PERC H710P Adapter, Mini Blade, and Mini Monolithic
- PERC H810 Adapter
- PERC S100
- PERC S110
- PERC S300
- Dell PowerEdge PCIe Express Flash SSD
- Internal Tape Adapter
The PERC 5/E Adapter supports the following Dell Storage systems: MD1000, MD1120
The PERC 5/E Adapter supports six enclosures
The following tables list the other elements supported by the PERC 5/E Adapter.
NOTE: The RAID cards support both 32-bit and 64-bit versions of Red Hat Enterprise Linux operating systems and
only 64-bit versions of the SUSE Linux Enterprise Server operating systems. However, all 64-bit versions of any
operating system are not supported.
Table 33. Storage Management Service Supported Elements: PERC 5/E Adapter
Storage
Management
Service
version
Server
Administrator
Version
PERC
Firmware
Version
Windows
Server 2008
32-bit Driver
Windows
Server 2008
64-bit Driver
Windows
Server 2008 R2
Driver
Windows
Server 2012
Driver
4.2 7.3 5.2.2-0076 2.24.0.32 2.24.0.64 4.5.0.64 Native
Red Hat
Enterprise
Linux 5.8
Driver
Red Hat
Enterprise
Linux 5.9
Driver
Red Hat
Enterprise
Linux 6.3
Driver
Red Hat
Enterprise
Linux 6.4
Driver
SUSE Linux
Enterprise
Server 10
SP3 Driver
SUSE Linux
Enterprise
Server 10
SP4 Driver
SUSE Linux
Enterprise
Server 11
SP1 Driver
SUSE Linux
Enterprise
Server 11
SP2 Driver
Native Native Native Native Native Native Native Native
PERC 5/i Adapter and Integrated
The PERC 5/i Adapter supports the following Dell PowerEdge systems: 1900, 1950, 1955, 2900, 2950, 2970, 6950, R610,
R710, T610, R410, T410, M610, M710, T710, T310, R310, R210, T110, R510, R810, R910, M910, R715, R815, R415, and R515.
The PERC 5/i Adapter supports the following Dell PowerVault system: PowerVault 100.
The PERC 5/i Integrated supports the following Dell PowerEdge systems: 1900, 1950, 1955, 2900, 2950, 2970, and 6950,
R610, R710, T610, R410, T410, M610, M710, T710, T310, R310, R210, T110, R510, R810, R910, M910, R715, R815, R415, and
R515.
The PERC 5/i Integrated supports the following Dell PowerVault system: PowerVault NX1950.
The following tables list the other elements supported by the PERC 5/i Adapter and Integrated.
Table 34. Storage Management Service Supported Elements: PERC 5/i Adapter and Integrated
Storage
Management
Service
version
Server
Administrator
Version
PERC
Firmware
Version
Windows
Server 2008
32-bit Driver
Windows
Server 2008
64-bit Driver
Windows
Server 2008 R2
Driver
Windows
Server 2012
Driver
4.2 7.3 5. 2.3-0074 2.24.0.32 2.24.0.64 4.5.0.64 Native
Red Hat
Enterprise
Linux 5.8
Red Hat
Enterprise
Linux 5.9
Red Hat
Enterprise
Linux 6.3
Red Hat
Enterprise
Linux 6.4
SUSE Linux
Enterprise
Server 10
SP3 Driver
SUSE Linux
Enterprise
Server 10
SP4 Driver
SUSE Linux
Enterprise
Server 11
SP1 Driver
SUSE Linux
Enterprise
Server 11
SP2 Driver
Native Native Native Native Native Native Native Native
SAS 5/iR Adapter and Integrated
The SAS 5/iR Adapter supports the following Dell PowerEdge systems: 1900, 2900, 6950, T605, and T610.
The SAS 5/iR Integrated supports the following Dell PowerEdge system: 1955.
