Reference Guide
Table Of Contents
- 1. Introduction
- Supported Dell OpenManage Systems Management Software
- This chapter contains information about Dell OpenManage systems management software, Dell OpenManage Server Administrator, on Dell systems running supported operating systems.
- Supported versions of Server Administrator are available at www.dell.com/support and also on the Dell Systems Management Tools and Documentation DVD.
- Supported Dell OpenManage Systems Management Consoles
- This chapter contains information about Dell OpenManage systems management consoles on Dell systems running supported operating systems. Dell OpenManage systems management consoles include:
- Dell OpenManage Power Center v1.2
- This chapter contains information about Dell Remote Access Controllers (DRAC), Integrated Dell Remote Access Controllers (iDRAC) versions and firmware, Baseboard Management Controllers (BMC) and IPMI prot...
- Supported Browsers
- This chapter lists the supported browsers on various operating systems for Dell systems.
- Network Interface Controllers and Supported Operating Systems
- This chapter contains information about Network Interface Controllers (NICs) and supported operating systems.
- RAID Controller Supported Servers, Operating Systems, Firmware, and Driver Versions
- 2. Supported Dell OpenManage Systems Management Software
- Documentation Conventions for Dell Systems
- The following table lists the documentation conventions followed for Dell systems.
- Supported Dell OpenManage Systems Management Software on Windows Operating Systems
- Supported Dell OpenManage Systems Management Software on Linux Operating Systems
- Supported Dell OpenManage Systems Management Software on Virtualization Operating Systems
- An X in the intersection of the operating system and the Dell system columns indicates that the Server Administrator and Dell Systems Build and Update Utility are supported on that operating system for the corresponding Dell system.
- An asterisk (*) in the intersection of the operating system and the Dell system columns indicates operating system support for Dell systems that do not support Dell OpenManage software.
- The following table lists the supported Dell OpenManage 7.2 installation and systems management software on systems running supported Virtualization operating systems.
- Table 2-4. Supported Dell OpenManage Systems Management Software on Systems Running Supported Virtualization Operating Systems
- 3. Supported Dell OpenManage Change Management Software
- Dell Yellow Dog Update Modified (YUM) Repository - The Dell Linux Community Repository helps distribute Dell-developed open-source software. It allows Dell user-community to contribute its open-source modules. It is available at http://linux.dell.co...
- Supported Change Management Software on Virtualization Operating Systems
- 4. Supported Dell OpenManage Systems Management Consoles
- 5. Dell OpenManage Systems Management Tools/Utilities
- Supported Microsoft Windows Pre-installation Environment for Deployment Toolkit v4.2
- Supported Microsoft Windows Operating Systems for VMCLI and iVMCLI
- IPMITool In-Band
- Supported Microsoft Windows Operating Systems for IPMITool In-Band
- IPMITool Out-of-Band
- Supported Linux Operating Systems for IPMITool
- Supported Virtualization Operating Systems for IPMITool
- 6. Supported Dell Remote Access Controllers and Solutions
- 7. Lifecycle Controller — Supported Dell Systems and Operating Systems
- 8. Supported Browsers
- 9. Network Interface Controllers and Supported Operating Systems
- 10. RAID Controller Supported Servers, Operating Systems, Firmware, and Driver Versions
- Linux Driver Included in RPM*
- PERC 5/E Adapter
- PERC 5/i Adapter and Integrated
- SAS 5/i Integrated
- SAS 5/E Adapter
- PERC 6/i Adapter, Integrated, and Modular
- CERC 6/i Integrated
- PERC 6/E Adapter
- SAS 6/iR Integrated and Adapter
- SAS 6/int Modular
- SAS 6 Gbps HBA
- LSI Logic 1020/1030 Ultra320 SCSI Adapter
- PERC H700 Adapter, Integrated, and Modular
- PERC H800 Adapter
- PERC H200 Adapter, Integrated, and Modular
- PERC H310 Adapter, Mini Blade, and Mini Monolithic
- PERC H710 Adapter, Mini Blade, and Mini Monolithic
- PERC H710P Adapter, Mini Blade, and Mini Monolithic
- PERC H810 Adapter
- PERC S100
- PERC S110
- PERC S300
- Dell PowerEdge PCIe Express Flash SSD
- Internal Tape Adapter
- Linux Driver Included in RPM*
PERC 5/E Adapter
The PERC 5/E Adapter supports the following Dell PowerEdge systems: 1900, 1950, 1955, 2900, 2950,
2970, 6950, R610, R710, T610, R410, T410, M610, M710, T710, T310, R310, R210, T110, R510, R810,
R910, M910, R715, R815, R415, R515, and R805.
The PERC 5/E Adapter supports the following Dell Storage systems: MD1000, MD1120
The PERC 5/E Adapter supports six enclosures.
The following tables list the other elements supported by the PERC 5/E Adapter.
NOTE:
The RAID cards support both 32-bit and 64-bit versions of Red Hat Enterprise Linux
operating systems and only 64-bit versions of the SUSE Linux Enterprise Server operating
systems. However, all 64-bit versions of any operating system are not supported.
Table 10-1. Storage Management Service Supported Elements: PERC 5/E Adapter
Storage
Management
Service version
Server
Administrator
Version
PERC
Firmware
Version
Windows
Server 2008
32-bit Driver
Windows
Server 2008
64-bit Driver
Windows
Server
2008 R2
Driver
4.2
7.2
5.2.2-0076
2.24.0.32
2.24.0.64
4.5.0.64
Red Hat Enterprise
Linux 5.8 Driver
Red Hat Enterprise
Linux 6.3 Driver
SUSE Linux Enterprise
Server 10 SP4 Driver
SUSE Linux
Enterprise Server
11 SP2 Driver
Native
Native
Native
Native
PERC 5/i Adapter and Integrated
The PERC 5/i Adapter supports the following Dell PowerEdge systems: 1900, 1950, 1955, 2900, 2950,
2970, 6950, R610, R710, T610, R410, T410, M610, M710, T710, T310, R310, R210, T110, R510, R810, R910,
M910, R715, R815, R415, and R515.
The PERC 5/i Adapter supports the following Dell PowerVault system: PowerVault 100.
The PERC 5/i Integrated supports the following Dell PowerEdge systems: 1900, 1950, 1955, 2900,
2950, 2970, and 6950, R610, R710, T610, R410, T410, M610, M710, T710, T310, R310, R210, T110, R510,
R810, R910, M910, R715, R815, R415, and R515.
The PERC 5/i Integrated supports the following Dell PowerVault system: PowerVault NX1950.
The following tables list the other elements supported by the PERC 5/i Adapter and Integrated
Table 10-2. Storage Management Service Supported Elements: PERC 5/i Adapter and Integrated
Storage
Management
Service version
Server
Administrator
Version
PERC
Firmware
Version
Windows
Server 2008
32-bit
Driver
Windows
Server 2008
64-bit Driver
Windows
Server 2008
R2 Driver
4.2
7.2
5. 2.2-0072
2.24.0.32
2.24.0.64
4.5.0.64
