Reference Guide
Table Of Contents
- 1. Introduction
- Supported Dell OpenManage Systems Management Software
- This chapter contains information about Dell OpenManage systems management software, Dell OpenManage Server Administrator, on Dell systems running supported operating systems.
- Supported versions of Server Administrator are available at support.dell.com and also on the Dell Systems Management Tools and Documentation DVD.
- Supported Dell OpenManage Systems Management Consoles
- This chapter contains information about Dell OpenManage systems management consoles on Dell systems running supported operating systems. Dell OpenManage systems management consoles include:
- Dell OpenManage Power Center 1.1
- This chapter contains information about Dell Remote Access Controllers (DRAC), Integrated Dell Remote Access Controllers (iDRAC) versions and firmware, Baseboard Management Controllers (BMC) and IPMI prot...
- Supported Browsers
- This chapter lists the supported browsers on various operating systems for Dell systems.
- Network Interface Controllers and Supported Operating Systems
- This chapter contains information about Network Interface Controllers (NICs) and supported operating systems.
- RAID Controller Supported Servers, Operating Systems, Firmware, and Driver Versions
- 2. Supported Dell OpenManage Systems Management Software
- Documentation Conventions for Dell Systems
- The following table lists the documentation conventions followed for Dell systems.
- Supported Dell OpenManage Systems Management Software on Windows Operating Systems
- Supported Dell OpenManage Systems Management Software on Linux Operating Systems
- Supported Dell OpenManage Systems Management Software on Virtualization Operating Systems
- An X in the intersection of the operating system and the Dell system columns indicates that the Server Administrator and Dell Systems Build and Update Utility are supported on that operating system for the corresponding Dell system.
- An asterisk (*) in the intersection of the operating system and the Dell system columns indicates operating system support for Dell systems that do not support Dell OpenManage software.
- The following table lists the supported Dell OpenManage 7.1 installation and systems management software on systems running supported Virtualization operating systems.
- Table 2-4. Supported Dell OpenManage Systems Management Software on Systems Running Supported Virtualization Operating Systems
- 3. Supported Dell OpenManage Change Management Software
- Dell Yellow Dog Update Modified (YUM) Repository - The Dell Linux Community Repository helps distribute Dell-developed open-source software. It allows Dell user-community to contribute its open-source modules. It is available at http://linux.dell.co...
- Supported Change Management Software on Virtualization Operating Systems
- 4. Supported Dell OpenManage Systems Management Consoles
- 5. Dell OpenManage Systems Management Tools/Utilities
- Supported Microsoft Windows Pre-installation Environment for Deployment Toolkit
- Supported Microsoft Windows Operating Systems for VMCLI and iVMCLI
- IPMITool In-Band
- Supported Microsoft Windows Operating Systems for IPMITool In-Band
- IPMITool Out-of-Band
- Supported Linux Operating Systems for IPMITool
- Supported Virtualization Operating Systems for IPMITool
- 6. Supported Dell Remote Access Controllers and Solutions
- 7. Supported Browsers
- 8. Network Interface Controllers and Supported Operating Systems
- 9. RAID Controller Supported Servers, Operating Systems, Firmware, and Driver Versions
- Linux Driver Included in RPM*
- PERC 5/E Adapter
- PERC 5/i Adapter and Integrated
- SAS 5/i Integrated
- SAS 5/E Adapter
- PERC 6/i Adapter, Integrated, and Modular
- CERC 6/i Integrated
- PERC 6/E Adapter
- SAS 6/iR Integrated and Adapter
- SAS 6/int Modular
- SAS 6 Gbps HBA
- LSI Logic 1020/1030 Ultra320 SCSI Adapter
- PERC H700 Adapter, Integrated, and Modular
- PERC H800 Adapter
- PERC H200 Adapter, Integrated, and Modular
- PERC H310 Adapter, Mini Blade, and Mini Monolithic
- PERC H710 Adapter, Mini Blade, and Mini Monolithic
- PERC H710P Adapter, Mini Blade, and Mini Monolithic
- PERC H810 Adapter
- PERC S100
- PERC S110
- PERC S300
- Dell PowerEdge PCIe Express Flash SSD
- Internal Tape Adapter (ITA)
- Linux Driver Included in RPM*
- 10. Lifecycle Controller — Supported Dell Systems and Operating Systems
M805 iDRAC 1.52
4.1
N/A 2.0
M905 iDRAC 1.52
4.1
N/A 2.0
1955 DRAC/MC 1.5 N/A 2.03 2.0
1855 DRAC/MC 1.5 N/A 1.01 or later 1.5
Table 6-2. Supported Remote Access Controllers and Solutions for Rack and Tower Servers
Dell
System
DRACs
BMC Firmware
Version
Supported IPMI
Protocol Versions
DRAC
Type
Supported DRAC
Firmware Version
R320 iDRAC7 1.20.20 N/A 2.0
R420 iDRAC7 1.20.20 N/A 2.0
R520 iDRAC7 1.20.20 N/A 2.0
R620 iDRAC7 1.20.20 N/A 2.0
R720 iDRAC7 1.20.20 N/A 2.0
R720XD iDRAC7 1.20.20 N/A 2.0
R820 iDRAC7 1.20.20 N/A 2.0
T320
iDRAC7 1.20.20 N/A 2.0
T420
iDRAC7 1.20.20 N/A 2.0
T620
iDRAC7 1.20.20 N/A 2.0
R210 iDRAC6 1.8 N/A 2.0
R210 II iDRAC6 1.8 1.8 2.0
R300 DRAC 5 1.6 2.34 2.0
R310 iDRAC6 1.8 N/A 2.0
R410 iDRAC6 1.8 N/A 2.0
R415 iDRAC6 1.8 1.8 2.0
R510 iDRAC6 1.8 N/A 2.0
R515 iDRAC6 1.8 1.8 2.0
R610 iDRAC6 1.8 N/A 2.0
R710 iDRAC6 1.8 N/A 2.0
R715 iDRAC6 1.8 N/A 2.0
R810 iDRAC6 1.8 N/A 2.0
R910
iDRAC6 1.8
N/A 2.0
R815 iDRAC6 1.8 N/A 2.0
T310
iDRAC6 1.8 N/A 2.0
T410
iDRAC6 1.8 1.8 2.0
T610
iDRAC6 1.8 N/A 2.0
T710
iDRAC6 1.8 N/A 2.0
PowerVault
DL2200
iDRAC6 1.8 1.7 2.0
PowerVault
NX3000
iDRAC6 1.8 N/A 2.0
PowerVault
NX3100
iDRAC6 1.8 N/A 2.0
PowerVault
NX200
iDRAC6 1.8 N/A 2.0
PowerVault
NX300
iDRAC6 1.8 1.7 2.0
