Table 34. Possible scenarios for reconfiguring a virtual disk (continued)

Controller Starting RAID Level Target RAID Level Comments

Mini Blades, PERC H730P

Adapter, PERC H730P Mini

Monolithic, PERC H730P Mini

Blades, PERC H730P Slim,

PERC H740P Adapter, PERC

H740P Mini Monolithic, PERC

H830 Adapter, PERC H840

Adapter, PERC H730P MX,

PERC H745P MX PERC

FD33xD/FD33xS, PERC

H745, PERC H345 Adapter,

PERC H755 Front, PERC

H755 Adapter and PERC

755N

RAID 6 requires a minimum of

4 disks.

RAID 5 RAID 0 With or without adding

additional disks

RAID 5 RAID 5, RAID 6 Add at least one additional

disk.

RAID 6 requires a minimum of

4 disks.

RAID 6 RAID 0, RAID 5 With or without adding

additional disks

RAID 6 RAID 6 Add at least one additional

disk

RAID 10 RAID 10 With or Without adding

additional disks

PERC S100, S110, S130, S140,

S300, and S150

RAID 0 RAID 0 With or without additional

disks

RAID 1 RAID 1 Without additional disks

RAID 5 RAID 5 With or without additional

disks

RAID 10 RAID 10 Without additional disks

NOTE: The order of the controllers displayed on Storage Management may differ with the order of the controllers displayed

in the Human Interface (HII) and PERC Option ROM. The order of the controllers does not cause any limitation.

NOTE: When creating virtual disks using software RAID controllers, the information related to the physical disks linked to

the virtual disk is enumerated or displayed on Storage Management after a short delay. This delay in displaying the

information does not cause any functional limitation. If you are creating partial virtual disks, it is recommended that you

provide Storage Management adequate time between each partial virtual disk creation process.

NOTE: RAID 10 virtual disk reconfiguration operation is not supported with Intelligent Mirroring.

Maintaining The Integrity Of Redundant Virtual Disks

Does my controller support this feature? See Supported Features.

The virtual disk Check Consistency task verifies the accuracy of the redundant (parity) information. This task only applies to

redundant virtual disks. When necessary, the Check Consistency task rebuilds the redundant data.

To verify redundant information of a virtual disk:

1. Locate the controller on which the virtual disk resides in the tree view. Expand the controller object until the Virtual Disks

object is displayed.

2. Select the Check Consistency task from the virtual disk’s Tasks drop-down list box and click Execute.

Rebuilding Redundant Information

Does my controller support this feature? See Supported Features.

If you have a redundant virtual disk, you can reconstruct the contents of a failed physical disk onto a new disk or a hot spare. A

rebuild can take place during normal operation, but it degrades performance.

A global hot spare drive can be part of different RAID level Virtual drives rebuilding operation on SWRAID controllers.

Virtual Disks

127
