Table 49. Virtual Disk Specifications for PERC S100, PERC S110, PERC S130, PERC S300 , PERC S140
and PERC S150 Controllers (continued)
Virtual Disk
Specification
PERC S100 PERC S110 PERC S130 PERC S300 PERC S140 PERC S150
Maximum Number
of Spans per
Virtual Disk
NA NA NA NA NA NA
Maximum Number
of Physical Disks
per Span
NA NA NA NA NA NA
Minimum Stripe
Size
64 K 64 K 64 K 64 K 64 K 64 K
Maximum Stripe
Size
64 K 64 K 64 K 64 K 64 K 64 K
Maximum Number
of Virtual Disks
per Physical Disk
8 8 10 8 30 8
Maximum Number
of Physical Disks
that Can Be
Concatenated
NA NA NA NA NA NA
Maximum Number
of Physical Disks
in a RAID 0
8 4 10 8 16 16
Maximum
Physical Disks in a
RAID 1
2 2 2 2 2 2
Maximum Number
of Physical Disks
in a RAID 5
8 4 10 8 16 16
Maximum Number
of Physical Disks
in a RAID 10
4 4 10 4 16 16
Minimum Number
of Physical Disks
that Can Be
Concatenated
NA NA NA NA NA NA
Minimum Number
of Physical Disks
in a RAID 0
2 2 2 2 2 2
Minimum Number
of Physical Disks
in a RAID 1
2 2 2 2 2 2
Minimum Number
of Physical Disks
in a RAID 5
3 3 3 3 3 3
Minimum Number
of Physical Disks
in a RAID 10
4 4 4 4 4 4
NOTE: When creating virtual disks using software RAID controllers, the information related to the physical disks linked
to the virtual disk is enumerated or displayed on Storage Management after a short delay. This delay in displaying the
