Reconfiguring Or Migrating Virtual Disks

Does my controller support this feature? See Supported Features.

Reconfiguring or migrating a virtual disk enables you to increase the capacity or change the RAID level of the virtual disk.

NOTE: On software RAID S110 and S130 controllers, if a physical disk (SATA SSD or HDD) is removed from a virtual disk

and the same physical disk is reinserted (hot plug) into the virtual disk instantly, within a fraction of a second, then the

virtual disk state is displayed as Ready and the physical disk state is displayed as Online. However, if the same physical disk

is reinserted after a short delay, then the virtual disk state is displayed as Degraded and the physical disk state is displayed

as Ready.

To reconfigure a virtual disk:

1. Review the information in Starting and Target RAID Levels for Virtual Disk Reconfiguration and Capacity Expansion.

2. Locate the controller on which the virtual disk resides in the tree view. Expand the controller object until the Virtual Disks

object is displayed.

3. Select the Reconfigure task from the virtual disk’s Tasks drop-down list box and click Execute.

4. Complete the Reconfigure task using the Reconfigure wizard.

Starting And Target RAID Levels For Virtual Disk

Reconfiguration And Capacity Expansion

After you have created a virtual disk, the possibilities for reconfiguring the virtual disk depend on the controller, RAID level, and

available physical disks.

Table 33. Possible scenarios for reconfiguring a virtual disk

Controller Starting RAID Level Target RAID Level Comments

PERC H800 Adapter, PERC

H700 Adapter, PERC H700

Integrated, and PERC H700

Modular, PERC H310 Adapter,

PERC H310 Mini Monolithic,

PERC H310 Mini Blades,

PERC H710 Adapter, PERC

H710 Mini Blades, PERC

H710 Mini Monolithic, PERC

H710P Adapter, PERC H710P

Mini Blades, PERC H710P

Mini Monolithic, PERC H810

Adapter, PERC H330 Adapter,

PERC H330 Mini Monolithic,

PERC H330 Mini Blades,

PERC H330 Embedded,

PERC H730 Adapter, PERC

H730 Mini Monolithic, PERC

H730 Mini Blades, PERC

H730P Adapter, PERC

H730P Mini Monolithic, PERC

H730P Mini Blades, PERC

H730P Slim, PERC H740P

Adapter, PERC H740P Mini

Monolithic, PERC H830

Adapter, PERC H840 Adapter,

PERC H730P MX, PERC

H745P MX PERC FD33xD/

FD33xS, PERC H745, and

PERC H345 Adapter

RAID 0

RAID 1 Add a single disk

RAID 0 RAID 0, RAID 5 Add at least one additional

disk.

RAID 0 RAID 6 RAID 6 requires a minimum of

4 disks.

Reconfiguration from RAID

0 to RAID 6 requires at

least 2 additional disks even

when this exceeds the 4-disk

minimum required by RAID 6

RAID 1 RAID 0 With or without adding

additional disks

RAID 1 RAID 5, RAID 6 Add at least one additional

disk.

RAID 6 requires a minimum of

4 disks.

RAID 5 RAID 0 With or without adding

additional disks

RAID 5 RAID 5, RAID 6 Add at least one additional

disk.

RAID 6 requires a minimum of

4 disks.

RAID 6 RAID 0, RAID 5 With or without adding

additional disks

Virtual Disks 121
