• Viewing Basic Information
• Conguring The Remote Access Device To Use A LAN Connection
• Conguring The Remote Access Device To Use A Serial Over LAN Connection
• Conguring The Remote Access Device To Use A Serial Port Connection
• Additional Conguration For iDRAC
• Conguring Remote Access Device Users
• Setting Platform Event Filter Alerts
You can view BMC/iDRAC or DRAC information based on which hardware is providing the remote access capabilities for the system.
The reporting and conguration of BMC/iDRAC and DRAC can also be managed using the omreport/omconfig chassis
remoteaccess command-line interface (CLI) command.
In addition, the Server Administrator Instrumentation Service allows you to manage the Platform Event Filters (PEF) parameters and
alert destinations.
Viewing Basic Information
You can view basic information about the BMC/iDRAC, IPv4 Address, and DRAC. You can also reset the Remote access controller
settings to their default values. To do this:
NOTE: You must be logged in with Administrator privileges to reset the BMC settings.
Click the Modular Enclosure → System/Server Module → Main System Chassis/Main System → Remote Access
The Remote Access page displays the following base information of the system’s BMC:
Remote Access Device
• Device Type
• IPMI Version
• System GUID
• Number of Possible Active Sessions
• Number of Current Active Sessions
• LAN Enabled
• SOL Enabled
• MAC Address
IPv4 Address
• IP Address Source
• IP Address
• IP Subnet
• IP Gateway
IPv6 Address
• IP Address Source
• IPv6 Address 1
• Default Gateway
• IPv6 Address 2
• Link Local Address
• DNS Address Source
• Preferred DNS Server
• Alternate DNS Server
49
