User's Manual


Enclosure Tasks
To execute a drop-down menu enclosure task:

1. Expand the Storage tree object to display the controller objects.

2. Expand a controller object.

3. Expand a Connector object.

4. Select the enclosure object.

5. Select the Information/Configuration subtab.

6. Select a task from the Available Tasks drop-down menu.

7. Click Execute.

Drop-down Menu Enclosure Tasks:
l Enable Alarm (Enclosure)
l Disable Alarm (Enclosure)
l Set Asset Data
l Blink
l Set Temperature Probe Values

Available Reports
To view a report:

1. Expand the Storage tree object to display the controller objects.

2. Expand a controller object.

3. Expand a Connector object.

4. Select the enclosure object.

5. Select the Information/Configuration subtab.

6. Select a report from the Select Report drop-down menu.

7. Click Execute.

Available Reports
l View Slot Occupancy Report

Enable Alarm (Enclosure)

Does my enclosure support this feature? See Supported Features.
Use the Enable Alarm task to enable the enclosure alarm. When enabled, the audible alarm sounds whenever the fault LED lights. This may occur to signal
events such as:
Enclosure Part
Number
This property displays the part number of the enclosure.
Enclosure Alarm
This property displays whether the enclosure's alarm is enabled or disabled.
