User's Manual

6. Click Execute.

Connector Components
For information on attached components, see the following topic:
l Enclosure and Backplane Properties and Tasks
Logical Connector Properties and Tasks
Use this window to view information about the logical connector (connector in redundant path mode) and to execute connector tasks.

Logical Connector Properties
The connector properties can vary depending on the model of the controller. Connector properties may include:
Table 8-3. Logical Connector Properties

Path Health
The path health of the connectors is represented as normal, warning, or critical. The possible values are displayed as Available, Degraded, or Failed.
If the enclosure health is displayed as degraded and further investigation shows all enclosure components (EMMs, Fans, Physical Disks, Power Supplies, and
Temperature) to be in normal condition, select the Information/Configuration subtab of the enclosure to view details of the Path Failure.

Clearing the Redundant Path View
If you do not want the redundant path view, physically disconnect the connector port from the enclosure and reboot the system. After the system reboots, the
user interface still displays the Logical Connector, but in a critical state. If you are certain you do not want the redundant path mode, select Clear Redundant
Path view from the Controller Tasks.
Selecting this option clears the redundant path view and the connectors are represented on the user interface as Connector 0 and Connector 1.

Related Tasks
l Redundant Path Configuration

Logical Connector Components
For information on attached components, see the following topic:
l Enclosure and Backplane Properties and Tasks

Property

Definition
These icons represent the severity or health of the storage component. For more information, see Storage Component Severity.
A Warning or Critical severity may indicate that the connector is unable to communicate with attached devices such as an enclosure. Check
the status of attached devices. For more information, see Cables Attached Correctly and Isolate Hardware Problems.
Name
This property displays the connector number, usually 0.
State
This property displays the current status of the connector. Possible values are:
Ready—The connector is functioning normally.
Degraded—The connector has encountered a failure and is operating in a degraded state.
Failed—The connector has encountered a failure and is no longer functioning.
Connector
Type
This property displays whether the connector is operating in RAID mode. The connector is always a SAS connector.
