94 Working with Remote Access Controller
5
Configure the following optional VLAN configuration details:
NOTE: VLAN configuration is not applicable for systems with iDRAC
– Enable VLAN ID
–VLAN ID
–Priority
6
Configure the following IPv4 Properties:
– IP Address Source
–IP Address
–Subnet Mask
– Gateway Address
7
Configure the following IPv6 Properties:
– IP Address Source
–IP Address
–Prefix Length
–Default Gateway
– DNS Address Source
– Preferred DNS Server
– Alternate DNS Server
NOTE: You can configure the IPv4 and IPv6 address details only if you enable
the IPv4 and IPv6 properties under Additional Configuration.
8
Click
Apply Changes.
Configuring the Remote Access Device to use a
Serial Port Connection
You can configure the BMC for communication over a serial port connection.
To do this:
1
Click the
Modular Enclosure
System/Server Module
Main System
Chassis/Main System
Remote Access
.
2
Click the
Configuration
tab.
