Server Administrator Services 83
Users
Subtab: Users
Under the Users tab, you can modify the remote access user configuration.
You can add, configure, and view information about Remote Access
Controller users.
NOTE: On the Dell PowerEdge x9xx systems:
- Ten user IDs are displayed. If a DRAC card is installed, sixteen user IDs are
displayed.
- Serial Over LAN Payload column is displayed.
Removable Flash Media
Click the Removable Flash Media object to view the health and redundancy
status of the Internal SD Modules and vFlash media. The Removable Flash
Media action window has the Properties tab.
Properties
Subtab: Information
Under the Properties tab, you can view information about the Removable
Flash Media and Internal SD Modules. This includes details about the
Connector Name, its state and storage size.
Alert Management
Subtabs: Alert Actions | SNMP Traps
Under the Alert Management tab, you can:
• View current alert actions settings and set the alert actions that you want
to be performed in the event that the removable flash media probe returns
a warning or failure value.
• View current SNMP trap alert thresholds and set the alert threshold levels
for removable flash media probes. The selected traps are triggered if the
system generates a corresponding event at the selected severity level.
Alert management is common for Internal SD modules and vFlash.
Configuring alert actions/SNMP/PEF for either the SD modules or vFlash
automatically configures it for the other.
