system's chassis. The Intrusion object action window can have the following
tabs, depending on the user's group privileges: Properties and Alert
Management.
Properties
Subtab: Intrusion
Under the Properties tab, you can view the chassis intrusion status.
Alert Management
Subtabs: Alert Actions | SNMP Traps
Under the Alert Management tab, you can:
• View current alert actions settings and set the alert actions that you want
to be performed in the event that the intrusion sensor returns a warning or
failure value.
• View current SNMP trap alert thresholds and set the alert threshold levels
for the intrusion sensor. The selected traps are triggered if the system
generates a corresponding event at the selected severity level.
Memory
Click the Memory object to manage your system's memory devices.
Server Administrator monitors the memory device status for each memory
module present in the monitored system. Memory device prefailure sensors
monitor memory modules by counting the number of ECC memory
corrections. Server Administrator also monitors memory redundancy
information if your system supports this feature. The Memory object action
window can have the following tabs, depending on the user's group privileges:
Properties and Alert Management.
Properties
Subtab: Memory
Under the Properties tab, you can view memory attributes, memory device
details, and memory device status.
NOTE: If a system with spare bank memory enabled enters a redundancy lost state,
it may not be apparent which memory module is the cause. If you cannot determine
which DIMM to replace, see the switch to spare memory bank detected log entry in
the ESM system log to find which memory module failed.
