Server Administrator Services 71
• View current Platform Event Filter settings and set the Platform Event
Filtering actions to be performed in the event that a system component
sensor returns a warning or failure value. You can also use the
Configure
Destination
option to select a destination (IPv4 or IPv6 address) where an
alert for a platform event is to be sent.
NOTE: Server Administrator does not display the scope ID of the IPv6 address in its
graphical user interface.
• View current SNMP trap alert thresholds and set the alert threshold levels
for instrumented system components. The selected traps are triggered if
the system generates a corresponding event at the selected severity level.
NOTE: Alert actions for all potential system component sensors are listed on
the Alert Actions window, even if they are not present on your system. Setting
alert actions for system component sensors that are not present on your
system has no effect.
Session Management
Subtabs: Session
Under the Session Management tab, you can:
• View session information for current users that have logged in to Server
Administrator.
• Terminate user sessions.
NOTE: Only users with administrative privileges can view the Session
Management page and terminate session(s) of logged-in users.
Main System Chassis/Main System
Click the Main System Chassis/Main System object to manage your system's
essential hardware and software components.
The available components are:
• Batteries
•BIOS
•Fans
•Firmware
• Hardware Performance
•Intrusion
