68 Server Administrator Services
Modular Enclosure
NOTE: For the purposes of Server Administrator, modular enclosure refers to a
system that may contain one or more modular systems that appear as a separate
Server Module in the system tree. Like a stand-alone Server Module, a Modular
Enclosure contains all of the essential components of a system. The only difference
is that there are slots for at least two Server Modules within a larger container,
and each of them is as complete a system as a Server Module.
To view the modular system’s chassis information and
Chassis Management
Controller (CMC) information, click
the Modular Enclosure object
.
Properties
Subtabs: Information
Under the Properties tab, you can:
• View the chassis information for the modular system being monitored.
• View detailed Chassis Management Controller (CMC) information for the
modular system being monitored.
Accessing and Using Chassis Management Controller
To link to the Chassis Management Controller Log in window from the
Server Administrator home page:
1
Click the
Modular Enclosure
object
2
Click the
CMC Information
tab, and then click
Launch the CMC Web
Interface
. The CMC
Log in
window is displayed.
You can monitor and manage your modular enclosure after connecting to the
CMC.
System/Server Module
The System/Server Module object contains three main system component
groups: "Main System Chassis/Main System," "Software," and "Storage."
The Server Administrator home page defaults to the System object of the
system tree view. Most administrative functions can be managed from the
System/Server Module object action window. The System/Server Module
object action window has the following tabs, depending on the user's group
privileges: Properties, Shutdown, Logs, Alert Management, and Session
Management.
