Setting Alert Actions 109
Chassis Intrusion
Detected
The system chassis has been opened.
Redundancy (PS or Fan)
Degraded
Redundancy for the fans and/or power supplies has
been reduced.
Redundancy (PS or Fan)
Lost
No redundancy remains for the system's fans and/or power
supplies.
Processor Warning A processor is running at less than peak performance or
speed.
Processor Failure A processor has failed.
PPS/VRM/DCtoDC
Wa rn in g
The power supply, voltage regulator module, or DC to
DC converter is pending a failure condition.
Power Supply/VRM/D2D
Failure
The power supply, voltage regulator module, or DC to
DC converter has failed.
Hardware log is full or
emptied
Either an empty or a full hardware log requires
administrator attention.
Automatic System
Recovery
The system is hung or is not responding and is taking an
action configured by Automatic System Recovery.
System Power Probe
Wa rn in g
The power consumption is approaching the failure
threshold.
System Power Probe
Failure
The power consumption has crossed the highest
acceptable limit and has resulted in a failure.
Removable Flash
Media Present
The removable flash media is present.
Removable Flash
Media Failure
The removable flash media is pending a failure condition.
Removable Flash
Media Warning
The removable flash media is present.
Table 7-1. PEF Alert Events
(continued)
Event Description
