90 Working with Remote Access Controller
IPv4 Address
• IP Address Source
• IP Address
• IP Subnet
•IP Gateway
IPv6 Address
• IP Address Source
• IPv6 Address 1
• Default Gateway
• IPv6 Address 2
• Link Local Address
• DNS Address Source
• Preferred DNS Server
• Alternate DNS Server
NOTE: You will be able to view IPv4 and IPv6 address details only if you enable
the IPv4 and IPv6 address properties under Additional Configuration in the
Remote Access tab.
Configuring the Remote Access Device to use a
LAN Connection
NOTE: The LAN configuration fields are displayed as read-only if they are
configured as
disabled
for inband users.
You can configure the remote access device for communication over
a LAN connection. To do this:
1
Click the
Modular Enclosure
→
System/Server Module
→
Main System
Chassis/Main System
→
Remote Access
object.
2
Click the
Configuration
tab.
3
Click
LAN
.
The
LAN Configuration
window appears.
NOTE: BMC/iDRAC management traffic will not function properly if the LAN
on motherboard (LOM) is teamed with any network adapter add-in-cards.
