66 Server Administrator Services
• View and configure asset information for the system being monitored.
• View and set the Automatic System Recovery (OS watchdog timer) actions
for the system being monitored.
NOTE: Automatic System Recovery options may not be available because the
operating system watchdog timer is enabled in BIOS. To configure the auto
recovery options, the operating system watchdog timer must be disabled.
NOTE: Automatic System Recovery actions may not execute exactly per the
time-out period (n seconds) when the watchdog identifies a system that has
stopped responding. The action execution time ranges from n-h+1 to n+1
seconds, where n is the time-out period and h is the heart beat interval. The
value of the heart beat interval is 7 seconds when n ≤ 30 and 15 seconds when
n > 30.
NOTE: The functionality of the watchdog timer feature cannot be guaranteed
when an uncorrectable memory event occurs in the system DRAM Bank_1.
If an uncorrectable memory event occurs in this location, the BIOS code
resident in this space may become corrupted. Because the watchdog feature
uses a call to BIOS to effect the shutdown or reboot behavior, the feature may
not work properly. If this occurs, you must manually reboot the system.
Shutdown
Subtabs: Remote Shutdown | Thermal Shutdown | Web Server Shutdown
Under the Shutdown tab, you can:
• Configure the operating system shutdown and remote shutdown options.
• Set the thermal shutdown severity level to shut down your system in the
event that a temperature sensor returns a warning or failure value.
NOTE: A thermal shutdown occurs only when the temperature reported by
the sensor goes above the temperature threshold. A thermal shutdown does
not occur when the temperature reported by the sensor goes below the
temperature threshold.
• Shut down the DSM SA Connection Service (Web server).
NOTE: Server Administrator is still available using the command line
interface (CLI) when the DSM SA Connection Service is shut down.
The CLI functions do not require the DSM SA Connection Service to
be running.
