Traps 711
356096 Chassis Intrusion - Physical Security
Violation
Critical
356224 Chassis Intrusion (Physical Security
Violation) Event Cleared
Informational
262400 Generic Predictive Fan Failure
(predictive failure asserted)
Minor
262528 Generic Predictive Fan Failure Cleared Informational
262402 Generic Critical Fan Failure Critical
262530 Generic Critical Fan Failure Cleared Informational
264962 Fan redundancy has been degraded Wa r ni ng
264961 Fan Redundancy Lost Critical
264960 Fan redundancy Has Returned to Normal Informational
2715392 Battery Low (Predictive Failure) Wa r ni ng
2715520 Battery Low (Predictive Failure)
Cleared
Informational
2715393 Battery Failure Critical
2715521 Battery Failure Cleared Informational
487169 CPU Thermal Trip (Over Temperature
Shutdown)
Critical
487297 CPU Thermal Trip (Over Temperature
Shutdown) Cleared
Informational
487168 CPU Internal Error Critical
487296 CPU Internal Error Cleared Informational
487173 CPU Configuration Error Critical
487301 CPU Configuration Error Cleared Informational
487175 CPU Presence (Processor Presence
detected)
Informational
487303 CPU Not Present (Processor Not Present) Critical
487170 CPU BIST (Built In Self Test) Failure Critical
Table 26-19. BMC Traps
(continued)
Trap ID Description Severity
