702 Traps
Battery Traps
The BMC on some systems reports the status of batteries. Battery traps
provide status and warning information for batteries present in a system with
a BMC that reports the status of batteries.
Table 26-16. Battery Traps
Trap ID Description Severity Cause
Battery Normal
1702 Battery sensor returned
to a normal value
Sensor Location:
<Location in chassis>
Chassis Location: <Name
of chassis>
Previous state was:
<State>
Battery sensor status:
<status>
Information A battery sensor in the
specified system detected
that a battery transitioned
back to a normal state.
The sensor location,
chassis location, previous
state, and battery sensor
status are provided.
Battery Warning
1703 Battery sensor detected
a warning value
Sensor Location:
<Location in chassis>
Chassis Location: <Name
of chassis>
Previous state was:
<State>
Battery sensor status:
<status>
Warning A battery sensor in the
specified system detected
that a battery is in a
predictive failure state.
The sensor location,
chassis location, previous
state, and battery sensor
status are provided.
