696 Traps
Fan Enclosure Traps
Some systems are equipped with a protective enclosure for fans. Fan
enclosure traps monitor enclosures for whether foreign objects are present
and for how long a fan enclosure is absent from a chassis.
Table 26-11. Fan Enclosure Traps
Trap
ID
Description Severity Cause
Fan Enclosure Insertion
1452 Fan enclosure inserted
into system
Sensor location:
<Location in chassis>
Chassis location:
<Name of chassis>
Information A fan enclosure has been
inserted into the specified
system. The sensor
location and chassis
location are provided.
Fan Enclosure Removal
1453 Fan enclosure removed
from system
Sensor location:
<Location in chassis>
Chassis location:
<Name of chassis>
Warning A fan enclosure has been
removed from the specified
system. The sensor
location and chassis
location are provided.
Fan Enclosure Extended Removal
1454 Fan enclosure removed
from system for an
extended amount of
time
Sensor location:
<Location in chassis>
Chassis location:
<Name of chassis>
Error A fan enclosure has been
removed from the specified
system for a user-definable
length of time. The sensor
location and chassis
location are provided.
