Storage Management Group 577
Array Disk Manufacture Year
Array Disk Media Type
Array Disk Enclosure Connection Table
This table describes the connections among array disks, their enclosure, and
their associated controller. For each object in the table, its object "number"
corresponds to an instance number in the appropriate MIB table for that
object where all of the object properties can be found.
NOTE: Only array disks that are part of an enclosure will be listed in this table.
Backplanes are considered enclosures by Storage Management.
The following object sets up the Array Disk Enclosure Connection Table.
Name arrayDiskManufactureYear
Object ID 1.3.6.1.4.1.674.10893.1.20.130.4.1.34
Description Indicates the four digit year in which this disk was manufactured.
Syntax DisplayString
Access Read-only
Name arrayDiskMediaType
Object ID 1.3.6.1.4.1.674.10893.1.20.130.4.1.35
Description Indicates the media type of the array disk.
Syntax INTEGER
Access Read-only
Name arrayDiskEnclosureConnectionTable
Object ID 1.3.6.1.4.1.674.10893.1.20.130.5
Description Defines the array disk enclosure connection table.
Syntax SEQUENCE OF ArrayDiskEnclosureConnectionEntry
Access Not accessible
