490 Remote Access Group
Table 19-20. Remote SNMP Trap Control Capabilities
Variable Name:
DellRemoteSNMPTrapControlCapabilities
Data Type: Integer
Possible Data Values Meaning of Data Value
none(0) The SNMP trap destination has no control capabilities.
unknownCapabilities
(1)
The SNMP trap destination control capabilities are
unknown.
trapTestCapable(2) A SNMP trap test can be performed for the SNMP trap
destination.
Table 19-21. Remote SNMP Trap Control Settings
Variable Name:
DellRemoteSNMPTrapControlSettings
Data Type: Integer
Possible Data Values Meaning of Data Value
none(0) The SNMP trap destination has no control settings.
unknown(1) The SNMP trap destination control settings are
unknown.
trapTestCapable(2) A SNMP trap test will be performed for the SNMP
trap destination.
Table 19-22. Remote Dial-Up State Capabilities
Variable Name:
DellRemoteDialUpStateCapabilities
Data Type: Integer
Possible Data Values Meaning of Data Value
none(0) The dial-up functionality has no
state capabilities.
unknownCapabilities(1) The dial-up functionality state
capabilities are unknown.
enableCapable(2) The dial-up functionality can be
disabled or enabled.
