Remote Access Group 489
Table 19-17. Remote User Admin Alpha Baud Type
Variable Name:
DellRemoteUserAdminAlphaBaudType
Data Type: Integer
Possible Data Values Meaning of Data Value
other(1) The remote user alphanumeric baud rate is not one
of the following:
unknown(2) The remote user alphanumeric baud rate is unknown.
alphaBaud300(3) The remote user alphanumeric baud rate is 300.
alphaBaud1200(4) The remote user alphanumeric baud rate is 1200.
Table 19-18. Remote SNMP Trap State Capabilities
Variable Name: DellRemoteSNMPTrapStateCapabilities
Data Type: Integer
Possible Data Values Meaning of Data Value
none(0) The SNMP trap destination has no state capabilities.
unknownCapabilities
(1)
The SNMP trap destination state capabilities
are unknown.
enableCapable(2) The SNMP trap destination can be disabled or enabled.
notReadyCapable(4) The SNMP trap destination can be in the "not ready"
state.
Table 19-19. Remote SNMP Trap State Settings
Variable Name:
DellRemoteSNMPTrapStateSettings
Data Type: Integer
Possible Data Values Meaning of Data Value
none(0) The SNMP trap destination has no state settings.
unknown(1) The SNMP trap destination state settings are unknown.
enabled(2) The SNMP trap destination is enabled.
notReady(4) The SNMP trap destination is in the "not ready" state.
