484 Remote Access Group
Table 19-7. Remote Access LAN Settings
Variable Name:
DellRemoteAccessLANSettings
Data Type: Integer
Possible Data Values Meaning of Data Value
none(0) The remote access hardware has no LAN
settings.
unknown(1) The remote access hardware LAN settings are
unknown.
nicEnabled(2) The remote access hardware NIC is enabled.
nicDHCPEnabled(4) The remote access hardware NIC will use
DHCP to obtain an IP address.
Table 19-8. Remote Access Host Capabilities
Variable Name:
DellRemoteAccessHostCapabilities
Data Type: Integer
Possible Data Values Meaning of Data Value
none(0) The remote access hardware has no
host capabilities.
unknownCapabilities(1) The remote access hardware host
capabilities are unknown.
smtpEmailCapable(2) The remote access hardware
supports sending e-mail using SMTP.
tftpRemoteFloppyCapable(4) The remote access hardware supports
remote floppy boot using a TFTP server.
tftpRemoteFwUpdateCapable(8) The remote access hardware supports
remote firmware update using a TFTP
server.
