Remote Access Group 483
Table 19-5. Remote Access Monitor Settings
Variable Name:
DellRemoteAccessMonitorSettings
Data Type: Integer
Possible Data Values Meaning of Data Value
none(0) The remote access hardware has no
monitor settings.
unknown(1) The remote access hardware monitor settings
are unknown.
extPwrSupplyMonitorIfConn
ectedEnabled(2)
The remote access hardware will monitor the
external power supply, if connected.
extPwrSupplyMonitorAlways
EnabledEnabled(4)
The remote access hardware will always
monitor the external power supply.
Table 19-6. Remote Access Local Area Network (LAN) Capabilities
Variable Name:
DellRemoteAccessLANCapabilities
Data Type: Integer
Possible Data Values Meaning of Data Value
none(0) The remote access hardware has no
LAN capabilities.
unknownCapabilities(1) The remote access hardware LAN capabilities
are unknown.
nicCapable(2) The remote access hardware has a network
interface controller (NIC).
nicDHCPCapable(4) The remote access hardware NIC can use
DHCP to obtain an IP address.
