Local Response Agent Group 405
rebootCapable(16) The LRA can reboot the system.
powerCycleCapable(32) The LRA is capable of a system power
cycle.
powerOFFCapable(64) The LRA can shut the system power off.
executeApplicationCapable(256) The LRA can execute a user mode
application.
lraFullyCapable(383) The LRA has all of the preceding
capabilities.
Table 17-2. LRA Thermal Shutdown Capabilities Unique
Variable Name: DellLRAThermalShutdownCapabilitiesUnique
Data Type: Integer
Possible Data Values Meaning of Data Value
none(0) The LRA has no thermal shutdown
capabilities.
Unknown capabilities(1) The LRA’s thermal shutdown capabilities are
unknown.
enableCapable(2) The LRA can be disabled (offline, a binary
0 value) or enabled (online, a binary 1 value).
warningCapable(4) The LRA can carry out chassis-determined
action(s) when a warning condition is
detected.
enableOnWarningCapable(6) The LRA enables activation of chassis-
determined action(s) when a warning
condition is detected.
failureCapable(8) The LRA can carry out chassis-determined
action(s) when a failure condition is detected.
Table 17-1. LRA Capabilities Definitions
(continued)
Variable Name: DellLocalResponseAgentCapabilitiesUnique
Data Type: Integer
Possible Data Values Meaning of Data Value
