404 Local Response Agent Group
LRA Action Table User Application Name
LRA Action Table Settings Unique
Local Response Agent Variable Values
This section includes definitions for server administrator-specific variable
values used in this section.
Name lRAActionTableUserApplicationName
Object ID 1.3.6.1.4.1.674.10892.1.1500.20.1.3
Description When the "execute application value" is set, provides the
following user-assignable LRA information:
• Name of the user application executable path
• File name to execute
Syntax DisplayString (SIZE (0..256))
Access Read-write
Name lRAActionTableSettingsUnique
Object ID 1.3.6.1.4.1.674.10892.1.1500.20.1.4
Description Defines the LRA settings.
Syntax DellLocalResponseAgentSettingsUnique (See Table 17-3.)
Access Read-write
Table 17-1. LRA Capabilities Definitions
Variable Name:
DellLocalResponseAgentCapabilitiesUnique
Data Type: Integer
Possible Data Values Meaning of Data Value
speakerControlCapable(1) The LRA can issue a speaker beep.
consoleAlertCapable(2) The LRA can alert the console.
broadcastMessageCapable(4) The LRA can broadcast a message.
osShutDownCapable(8) The LRA can shut down the operating
system.
