360 Memory Group
Table 15-4. Physical Memory Configuration State Settings
Variable Name:
DellPhysicalMemoryConfigStateSettings
Data Type: Integer
Possible Data Values Meaning of Data Value
If set to 0 (zero) There are no state settings.
unknown(1) State settings are unknown.
enabled(2) Object is disabled (offline) 0,
or enabled (online) 1.
notReady(4) Object "not ready."
redundantMemoryIsActive(8) Redundant memory is active
(in use)
enabledAndRedundantMemoryIsActive(10) Redundant memory is
enabled and in use.
Table 15-5. Physical Memory Configuration Redundant Capabilities
Variable Name:
DellPhysicalMemoryConfigRedundantCapabilities
Data Type: Integer
Possible Data Values Meaning of Data Value
If set to 0 (zero) There are no redundant memory capabilities.
unknownCapabilities(1) Redundant capabilities are unknown.
The redundant capabilities are:
spareCapable(2) Spare redundant memory feature is supported.
mirrorCapable(4) Mirror redundant memory feature is supported.
spareAndMirrorCapable(6) Spare and mirror redundant memory features are
supported.
raidCapable(8) Redundant Array of Independent disks (RAID)
redundant memory feature is supported.
