Slot Group 335
systemSlotIsPCIExpressGen2X4(174) The system slot type is PCI Express
Gen 2 x4.
systemSlotIsPCIExpressGen2X8(175) The system slot type is PCI Express
Gen 2 x8.
systemSlotIsPCIExpressGen2X16(176) The system slot type is PCI Express
Gen 2 x16.
Table 14-4. System Slot Usage
Variable Name:
DellSystemSlotUsage
Data Type: Integer
Possible Data Values Meaning of Data Value
systemSlotUsageIsOther(1) The system slot usage is not one of
following:
systemSlotUsageIsUnknown(2) The system slot usage is unknown.
systemSlotUsageIsAvailable(3) The system slot is available.
systemSlotUsageIsInUse(4) The system slot is in use.
Table 14-5. System Slot Length
Variable Name: DellSystemSlotLength
Data Type: Integer
Possible Data Values Meaning of Data Value
systemSlotLengthIsOther(1) The system slot length is not one of
following:
systemSlotLengthIsUnknown(2) The system slot length is unknown.
systemSlotLengthIsShort(3) The system slot length is short.
systemSlotLengthIsLong(4) The system slot length is long.
Table 14-3. System Slot Type
(continued)
Variable Name: DellSystemSlotType
Data Type: Integer
Possible Data Values Meaning of Data Value
