314 Device Group
Table 13-11. Cache Device ECC Type
Variable Name:
DellPointingDeviceType
Data Type: Integer
Possible Data Values Meaning of Data Value
deviceTypeIsOther(1) Device type is not one of the following:
deviceTypeIsUnknown(2) Device type is unknown.
deviceTypeIsAMouse(3) Device type is a mouse.
deviceTypeIsATrackBall(4) Device type is a track ball.
deviceTypeIsATrackPoint(5) Device type is a track point.
deviceTypeIsAGlidePoint(6) Device type is a glide point.
deviceTypeIsATouchPad(7) Device type is a touch pad.
Table 13-12. Cache Device Associativity
Variable Name:
DellCacheDeviceAssociativity
Data Type: Integer
Possible Data Values Meaning of Data Value
deviceAssociativityIsOther(1) Device associativity is not
one of the following:
deviceAssociativityIsUnknown(2) Device associativity is
unknown.
deviceAssociativityIsDirectMapped(3) Device is direct mapped.
deviceAssociativityIsTwoWaySetAsso
ciative(4)
Device is two-way set
associative.
deviceAssociativityIsFourWaySetAsso
ciative(5)
Device is four-way set
associative.
deviceAssociativityIsFullyAssociative
(6)
Device is fully associative.
deviceAssociativityIsEightWaySetAsso
ciative(7)
Device is eight-way set
associative.
