Device Group 311
deviceFamilyIsG4(201) The processor family is G4.
deviceFamilyIsG5(202) The processor family is G5.
deviceFamilyIsESA390G6(203) The processor family is ESA/390 G6.
deviceFamilyIszArchitectur(204) The processor family is z/Architectur
base.
deviceFamilyIsVIAC7-M(210) The processor family is VIA C7(TM)-M.
deviceFamilyIsVIAC7-D(211) The processor family is family is VIA
C7(TM)-D.
deviceFamilyIsVIAC7(212) The processor family is VIA C7(TM).
deviceFamilyIsVIAEden(213) The processor family VIA Eden(TM).
deviceFamilyIsMultiCoreIntelXeo
n(214)
The processor family is Multi-Core Intel
Xeon processor.
deviceFamilyIsDualCoreIntelXeon
3xxx(215)
The processor family is Dual-Core Intel
Xeon processor 3xxx Series.
deviceFamilyIsQuadCoreIntelXeon
3xxx(216)
The processor family is Quad-Core Intel
Xeon processor 3xxx Series.
deviceFamilyIsDualCoreIntelXeon
5xxx(218)
The processor family is Dual-Core Intel
Xeon processor 5xxx Series.
deviceFamilyIsQuadCoreIntelXeon
5xxx(219)
The processor family is Quad-Core Intel
Xeon processor 5xxx Series.
deviceFamilyIsDualCoreIntelXeon
7xxx(221)
The processor family is Dual-Core Intel
Xeon processor 7xxx Series.
deviceFamilyIsQuadCoreIntelXeon
7xxx(222)
The processor family is Quad-Core Intel
Xeon processor 7xxx Series.
deviceFamilyIsMultiCoreIntelXeo
n7xxx(223)
The processor family is Multi-Core Intel
Xeon processor 7xxx Series.
deviceFamilyIsSixCoreAMDOpteron
(238)
The processor family is Six-Core AMD
Opteron™.
Table 13-6. Processor Device Family
(continued)
Variable Name: DellProcessorDeviceFamily
Data Type: Integer
Possible Data Values Meaning of Data Value
